Beelink SER9 MAX AMD Ryzen TM 7 H 255 (OpenClaw Pre-Installed)

The Beelink SER9 MAX is a compact mini PC with an AMD Ryzen 7 H 255 processor (8 cores, up to 4.9GHz) and Radeon 780M graphics. It supports up to 64GB of DDR5 5600 memory and dual M.2 PCIe 4.0 SSDs for up to 8TB storage. Connectivity includes 10Gbps LAN, WiFi 6, Bluetooth 5.2, and triple 4K@240Hz display output via HDMI 2.

Full Specifications

Processor	AMD Ryzen 7 H 255, 8C/16T, 3.8GHz Base / 4.9GHz Boost, 16MB L3 Cache, 65W TDP
Graphics	AMD Radeon 780M, 12 CUs, 2600MHz, RDNA 3 architecture
Display Support	Triple display: DP 2.1 (4K@240Hz) x 1 + HDMI 2.1 (4K@240Hz) x 1 + USB4 (40Gbps/TBT3/PD/DP1.4) x 1, max 4K output
Memory	DDR5 5600MT/s, SO-DIMM (16GBx2 or 32GBx2), configurations: 32GB or 64GB
Memory Slots	2 x SO-DIMM
Storage	Dual M.2 2280 PCIe 4.0 x4, max 8TB (4TB x 2)
Storage Expansion	Dual M.2 2280 PCIe 4.0 x4 slots, max 8TB total
I/O Ports	USB4 (40Gbps/TBT3/PD/DP1.4) x 1, HDMI 2.1 x 1, DisplayPort 2.1 x 1
Ethernet	10Gbps LAN x 1
Wireless	WiFi 6 (Intel AX200)
Bluetooth	Bluetooth 5.2
Operating System	Ubuntu / Windows 11 Pro
Power	19V 5.26A (~100W); Input: 200-240V AC, 50/60Hz (US/JP: 100-240V); US, EU, UK, AU, JP adapter options
Cooling	MSC 2.0 - Vapor Chamber + Silent Fan + SSD Heatsink, bottom dust filter
Dimensions	135 x 135 x 44.7mm (without rubber feet)
Weight	780g
Expansion Slots	2 x M.2 2280 (PCIe 4.0 x4) for SSD
Features	WOL (Wake-on-LAN), AUTO POWER ON, pre-installed OpenClaw, bottom dust filter
Overview	Beelink SER9 MAX mini PC powered by AMD Ryzen 7 H 255 (8C/16T) with Radeon 780M graphics, DDR5 5600 memory, dual M.2 PCIe 4.0 SSD slots up to 8TB, 10Gbps LAN, WiFi 6, Bluetooth 5.2, triple 4K@240Hz display output via HDMI 2.1, DP 2.1, and USB4, cooled by MSC 2.0 vapor chamber system, with OpenClaw pre-installed.
Warranty	Three-year warranty
Configurations	32GB (16GB x 2) DDR5 5600MHz + 1TB SSD (Pre-order) \| 32GB (16GB x 2) DDR5 5600MHz + 2TB SSD \| 64GB (32GB x 2) DDR5 5600MHz + 1TB SSD
