A9 Mega
The Geekom A9 Mega AI Mini PC features an AMD Ryzen AI Max+ 395 processor with 16 cores, 128GB LPDDR5x RAM, 2TB NVMe SSD, and dual expansion slots. It supports up to four 8K displays, dual 2.5G Ethernet, Wi-Fi 7, and Bluetooth 5.4. The system delivers 126 total TOPS with a 50+ TOPS NPU. It runs Windows 11 Pro and has a 330W power supply.
Pros
- +Radeon 8060S graphics with 50 TOPS NPU
- +Up to 128GB LPDDR5x-8000 memory
- +Dual PCIe Gen4x4 M.2 slots with RAID 0/1
- +Dual 2.5G Ethernet, Wi-Fi 7, Bluetooth 5.4
- +330W power supply for sustained 120W performance
- +Fingerprint security and DTPM2.0
Cons
- −RAM is soldered and not upgradeable
- −No Kensington lock slot
- −Heavy at 1.9 kg including adapter
- −High price of $3,999
| Model | A9 Mega |
| Processor | AMD Ryzen™ Al Max+ 395 | AMD Ryzen™ AI Max+ 395,16C/32T, 3GHz, Max 5.1GHz, cTDP 45-120W |
| Processor Model | AMD Ryzen AI Max+ 395 |
| Graphics | Radeon 8060S Graphics (for Max+ 395), Support 4 outputs, AMD Ryzen™ AI, NPU 50 TOPS |
| NPU / AI Accelerator | AMD Ryzen AI NPU, 50 TOPS |
| Memory | Support 8*Onboard LPDDR5x 8000MHz, up to 128GB |
| Memory Slots | 8 (onboard, soldered), max 128GB |
| Storage | 2 x M.2 2280 PCIe Gen4x4, supports 128GB~4TB NVMe SSD, support Raid 0 & Raid 1 |
| Storage Expansion | 2 x M.2 2280 slots, up to 8TB total |
| Display Support | 4 displays, 2 x HDMI 2.1 FRL up to 8K/60Hz, 2 x USB4 Type-C with DisplayPort 2.1 |
| Network | 2 x 2.5G RJ45 Ethernet, Wi-Fi 7, Bluetooth 5.4 |
| Wireless | Wi-Fi 7 | Wi-Fi 7 802.11be, 2.4GHz/5GHz, 6GHZ |
| Bluetooth | Bluetooth 5.4 |
| Ethernet | 2x RJ-45 Ethernet 10/100/1000/2500 Mbps |
| I/O Ports | 3 x USB 3.2 Gen 2 Type-A | 2 x USB 3.2 Gen 2 Type-C | 1 x USB 2.0 | 2 x USB4 Type-C | 1 x 3.5mm stereo headset jack | 2 x 2.5G RJ45 | 2 x HDMI 2.1 FRL | 1 x DC in | 1 x SD Card Reader 4.0 |
| Front I/O | 2 x USB 3.2 Gen 2 Type-A, 2 x USB 3.2 Gen 2 Type-C (data only), 1 x SD Card Reader SDXC |
| Rear I/O | 1 x USB 3.2 Gen 2 Type-A, 1 x USB 2.0, 2 x USB4 Type-C (40Gbps, DP 2.1), 2 x HDMI 2.1 FRL, 2 x 2.5G RJ45, 1 x 3.5mm stereo headset jack, 1 x DC in |
| SD Card | Yes |
| Dimensions | 6.73" × 6.73" × 2.79" (Including floor MATS) |
| Weight | 1.9KG(Includes adapter) |
| Color / Finish | Silver |
| Form Factor | Mini PC (NUC-like) |
| Power | 330W power supply adapter (20V 16.5A), AC input 100-240V 50-60Hz 4.2A |
| Power Options | Geo-specific AC cord (IEC C5) |
| Cooling | Dual fans + vapor chamber (IceBlast 5.0) |
| Operating System | Windows 11 Pro |
| Operating System Options | Windows 10 LTSC, Windows 11, Linux |
| Audio | 2 x Microphone, 1 x 3.5mm stereo headset jack |
| Expansion Slots | 2 x M.2 2280 Key-M (PCIe Gen4x4), 1 x M.2 2230 Key-E (PCIe 3.0 x1 for WiFi) |
| Environmental | Operating temperature: -0°C to 50°C, Storage: -20°C to 70°C, Humidity: 95% @ 40°C non-condensing |
| Security | 1 x DTPM2.0, Fingerprint button (USB interface, Support ESS) |
| Certifications | CE, FCC, CB, CCC, SRRC, RoHS |
| Kensington Lock | No |
| Features | The Ultimate AI Workstation | 120W Sustained | 126 Total TOPS | Next-Gen AI Powerhouse (126 Total TOPS): Unleash elite-level machine learning and creative workflows with 50+ NPU TOPS and a total system output of 126 TOPS, driven by the flagship AMD Ryzen TM AI Max+ 395 (16C/32T) for unthrottled workstation performance. | IceBlast 5.0 Thermal Mastery: Stay frost-bound with a precision-engineered dual-fan system and an ultra-slim, full-coverage vapor chamber, specifically designed to maintain a sustained 120W TDP without throttling-even under 100% load. | Massive 330W Power Reserve: Equipped with a professional-grade 330W power supply, providing the massive electrical overhead required for rock-solid stability and simultaneous CPU, GPU, and NPU peak-frequency bursts. | Ultra-Fast 128GB LPDDR5x & RAID Storage: Experience zero-bottleneck multitasking with up to 128GB of 8000MHz memory and dual M.2 PCIe Gen4x4 slots(up to 8TB) supporting RAID 0/1 for industrial-grade data transfer speeds. | Quad-8K Professional Workspace: A world-first in its class-drive four 8K displays simultaneously via dual 40Gbps USB4 and dual HDMI 2.1 (FRL) ports for the ultimate high-resolution creative or trading setup. | Industrial Build & Pro-Connectivity: A precision CNC-machined aluminium alloy chassis housing Wi-Fi 7, Bluetooth 5.4, dual 2.5G Ethernet, and integrated fingerprint security-combining rugged durability with elite networking. |
| Overview | Unleash the GEEKOM A9 Mega AI Mini PC, featuring the AMD Ryzen TM AI Max+ 395. Experience peak performance for AI workloads and creative tasks. Order yours today! |
| Configurations | Ryzen AI Max+ 395 128 GB RAM + 2 TB SSD |
Specs on this page may not be 100% accurate — please verify with the manufacturer.
