Beelink ME mini 6-slot Home Storage NAS Mini PC
The Beelink ME mini is a cube-shaped NAS mini PC with six M.2 2280 NVMe SSD slots (one for system, five for storage) supporting up to 24TB total. It features an Intel N95/N150 processor, LPDDR5 memory (12/16GB soldered), dual 2.5G Ethernet, WiFi 6, Bluetooth 5.2, and HDMI 2.0b 4K output. Built-in 45W PSU, quiet fan, and runs Windows 11 Home.
Pros
- +Six M.2 slots up to 24TB
- +Dual 2.5G LAN ports
- +Wi-Fi 6 and Bluetooth 5.2
- +Compact 99mm cube design
- +Silent fan cooling
- +HDMI 2.0 4K output
Cons
- −Soldered RAM max 16GB
- −Most M.2 slots limited to PCIe 3.0 x1
- −Only one SATA III compatible M.2 slot
- −Only one USB 3.2 10Gbps port
| Model | Beelink ME mini 6-slot Home Storage NAS Mini PC |
| Processor | Intel® N95/N150 Processor, 4 Cores 4 Threads, Burst Frequency: 3.4/3.6 GHz |
| Processor Model | Intel N150 |
| Processor Technology | Intel 7 (10nm Enhanced) |
| Graphics | Intel UHD Graphics (16 EU), up to 1.2 GHz |
| Memory | LPDDR5 4800MHz, Available: 12GB/16GB |
| Memory Slots | 0 (soldered, max 16GB) |
| Storage | Available: no EMMC, with EMMC 64GB/SSD4 M.2 2280 PCIe 3.0 (Compatible with SATA III SSD) | M.2 2280 PCIe3.0 x1(Max 4TB)*5, Optional: No SSD/2TB*1/2TB*2 (Incompatible with SATA III SSD) |
| Storage Expansion | -20°C-60°C, 10%-90% Humidity | Crucial P3 Plus 1TB/4TB | Aigo P7000E 4TB | Colorful CN700 4TB | Fanxiang S790E 4TB | Great Wall Gw7000 4TB | Hiksemi-A4000 4TB | Netac NV7000-Q 4TB | Yangtze YHTC PC410 1TB | WD BLACK SN850X 1TB | ZHITAI TiPIUS7100 1TB | Samsung SSD 970 EVO 1TB |
| Display Support | 1x HDMI 2.0, supports up to 4K@60Hz |
| Network | Dual 2.5G LAN (Intel i226-V) + WiFi 6 (Intel AX101) + Bluetooth 5.2 |
| Wireless | WiFi 6 (Intel AX101), Bluetooth 5.2 |
| Bluetooth | 5.2 |
| Ethernet | Chipset: Intel KTI226-V, Interface: PCIe, Data Rate: 10/100/1000/2500 Mbps |
| I/O Ports | USB2.0 480Mbps*1, USB3.2 10Gbps*1, LAN2.5G(inteli226-v)*2, Type-C10Gbps(Data)*1, HDMI(Max 4K 60Hz)*1 |
| Front I/O | 1x USB 3.2 Gen2 Type-C, 1x USB 3.2 Gen2 Type-A, power button, LEDs |
| Rear I/O | 1x USB 2.0, 1x HDMI, 2x RJ45 2.5G LAN, power connector |
| Dimensions | 99x99x99mm (With Rubber Feet) |
| Color / Finish | Pearl White, Peacock Blue, Midnight Gray |
| Form Factor | Mini PC / NAS cube |
| Power | 100-240V~, 50/60Hz, 1.5A |
| Power Options | US, EU, UK, AU, JP |
| Cooling | Active cooling with silent fan and vertical airflow |
| Operating System | Windows 11 Home |
| Operating System Options | Pearl White, Midnight Gray, Peacock Blue |
| Expansion Slots | 6x M.2 2280/2242/2230 PCIe 3.0 (1x x2, 5x x1), 1x M.2 E-key for WiFi (occupied) |
| Environmental | -10°C-45°C, 30%-90% Humidity |
| Support Included | 30-Day Risk-Free Trial, 3 Year Warranty |
| Package Contents | HDMI 100cm, User Manual, AC Cable |
| Features | About this item | - Massive Expandable Storage for Families---Up to 24TB Capacity: 6x M.2 SSD slots (supports 2230/2242/2280 sizes) for storing family memories-roughly 11,000 movies, 2.23 million songs, or 4.46 million photos. | - Seamless Sharing & Accessibility---Multi-OS Support: Ideal for family media systems (KODI, Plex, JellyFin, Emby) and home networks. | - Quiet & Compact Design for Home Use---Whisper-Quiet Operation: Silent fan and vertical airflow cooling ensure noise-free evenings. Palm-Sized: Fits discreetly in living rooms or home offices. | - Reliable Data Protection---Crucial SSDs: Enhanced durability and reduced risk of data loss. | - Built-in Power Supply Unit---Simplifies wiring with a single AC cable. | - | Dual 2.5G LAN + WiFi 6---Enables fast local sharing, link aggregation, soft router, and stable streaming. | - | Versatile Home Scenarios---Family Media Hub: Stream 4K videos, music, and photos to TVs or mobile devices. Baby Moments Archive: Securely store and share growth milestones with family. | Our US&JP power supply has a wide input voltage range from 100V to 240V. Although the power supply labels 100V-120V, it is safe to work with power source voltages anywhere between 100V to 240V. |
| Overview | The Beelink ME mini is a compact NAS mini PC designed for home storage, featuring up to 6 M.2 NVMe SSD slots, dual 2.5G LAN, and a silent cooling system. |
| Warranty | 3 Year Warranty |
| Configurations | N95+16GB LPDDR5-4800 memory (soldered) +64G eMMC <br>(No SSD/Bluetooth/WiFi Included) | N150+16GB LPDDR5-4800 memory (soldered)+1TB SSD |
Specs on this page may not be 100% accurate — please verify with the manufacturer.
