Beelink SER10 MAX AMD Ryzen™ AI 9 HX 470
The Beelink SER10 MAX features AMD Ryzen AI 9 HX 470 (12 cores, 5.2GHz), Radeon 890M graphics (16 CU), 86 TOPS NPU, up to 64GB DDR5, dual M.2 PCIe 4.0 slots, triple 4K display support, 10Gbps Ethernet, WiFi 6, and Windows 11 Pro.
Pros
- +AMD Ryzen AI 9 HX 470 12-core processor
- +86 AI TOPS NPU
- +Radeon 890M graphics
- +10GbE LAN
- +Dual M.2 PCIe 4.0 SSD slots
- +Triple 4K display support
| Model | SER10 MAX |
| Processor | AMD Ryzen™ AI 9 HX 470 12C/24T Max Boost Clock: 5.2GHz L2+L3 Cache 36MB |
| Processor Model | Ryzen AI 9 HX 470 |
| Graphics | AMD Radeon™ 890M Graphics Cores: 16 CU Graphics Frequency: 3100MHz |
| NPU / AI Accelerator | AMD XDNA 2 NPU, 86 AI TOPS |
| Memory | DDR5 5600MT/s |
| Memory Slots | 2, max 64GB |
| Storage | Dual M.2 2280 PCle4.0 X4 Max 8TB (4TB*2) |
| Storage Expansion | Dual M.2 2280 PCIe 4.0 x4 slots, supports up to 8TB total (2x4TB) |
| Display Support | DP(4K 240Hz)*1+HDMI(4K 240Hz)*1+ USB4 (40Gbps/PD/DP1.4)*1 Support 4K Output |
| Network | 10Gbps Ethernet, WiFi 6 (Intel AX200), Bluetooth 5.2 |
| Wireless | WiFi 6 (Intel AX200) Bluetooth 5.2 |
| Bluetooth | 5.2 |
| Ethernet | 10Gbps |
| Rear I/O | 1x DP, 1x HDMI, 1x USB4, 1x 10Gbps Ethernet, DC-in |
| Color / Finish | Frost Silver |
| Form Factor | Mini PC |
| Power | Input: 100-240V AC, 50/60Hz Output: 19V 5.26A |
| Power Options | US, EU, UK, AU, JP |
| Cooling | MSC 2.0 – Cooling System Vapor Chamber+Silent Fan+SSD Heatsink |
| Operating System | Windows 11 Pro |
| Operating System Options | Frost Silver |
| Sustainability | Climate Pledge Friendly |
| Features | AUTO POWER ON WOL | About this item | - Powerful AMD Ryzen TM AI 9 HX 470 CPU and AMD Radeon TM 890M GPU bring the Future to your Fingertips---12 Zen5 CPU cores, combined with a new Radeon TM 890M iGPU, a new generation XDNA 2 NPU and 86 AI TOPS, the Ryzen TM AI 9 HX470 processor's fully upgraded architecture significantly boosts the SER10 MAX's overall performance, delivering a faster, smarter, and more secure Al PC experience! | - 10Gbps Wired Networking - 4x Faster than 2.5G---The SER10 MAX features an upgraded 10Gbps LAN port, delivering four times the speed of standard 2.5Gbps Ethernet. This enables ultra-fast transfers of large files, swift backups, and low-latency connections-eliminating bottlenecks and delivering a seamless high-speed networking experience. | - MSC 2.0 Vapor Chamber Uniform Cooling Technology---The MSC 2.0 Vapor Chamber (VC) evenly and rapidly distributes CPU heat across the entire cooling surface, preventing localized hotspots and significantly improving thermal efficiency. By spreading heat instantly to every contact point, it enables faster heat dissipation, more stable performance under heavy workloads, and sustained peak output even during long-term, high-intensity operation. | - Storage Expansion Options --- SER10 MAX features high frequency DDR5 5600 MT/s RAM of 32GB/64GB, delivering you the smoothest experience in Al computing, gaming and multimedia entertainment. There are also dual high-speed M.2 2880 PCle4.0 SSD slots, supporting up to 8TB of fast internal storage. | - Triple-display Output---With HDMI 2.1 & DisplayPort & Full Featured USB4(40Gbps/PD/DP1.4), the SER10 MAX supports up to triple 4K displays. | Our US&JP power supply has a wide input voltage range from 100V to 240V. Although the power supply labels 100V-120V, it is safe to work with power source voltages anywhere between 100V to 240V. |
| Overview | Powerful AMD Ryzen AI 9 HX 470 mini PC with Radeon 890M graphics, 86 AI TOPS, 10Gbps Ethernet, triple 4K display support, MSC 2.0 cooling. |
| Warranty | Three-year Warranty |
| Configurations | 32GB (16G*2) DDR5 5600 MT/s + 1TB SSD | 64GB (32G*2)DDR5 5600 MT/s + 1TB SSD (Pre-order) |
