Beelink SER8 8745HS
The Beelink SER8 mini PC packs an AMD Ryzen 7 8745HS processor and Radeon 780M graphics. It supports up to 256GB DDR5 RAM and 8TB storage via dual M.2 slots. Connectivity includes 2.5Gb Ethernet, WiFi 6, Bluetooth 5.2, and triple 4K display output. Its MSC 2.0 cooling ensures near-silent 32dB operation, and a dustproof design enhances durability.
Pros
- +Fast AMD Ryzen 7 8745HS processor
- +Powerful Radeon 780M integrated graphics
- +Up to 256GB DDR5 5600MHz RAM
- +Triple 4K display support with USB4
- +2.5GbE Ethernet and WiFi 6
- +Near-silent cooling with dustproof design
Cons
- −No NPU / AI engine
- −No SD card slot
| Model | SER8 8745HS |
| Processor | AMD Ryzen™ 7 8745HS 8C/16T 4.9GHz Max Turbo Frequency 16MB L3 Cache |
| Processor Model | AMD Ryzen 7 8745HS |
| Graphics | AMD Radeon™ 780M 12 Cores 2600 MHz |
| NPU / AI Accelerator | None |
| Memory | Dual SO-DIMM DDR5 5600MHz Slot Max 256GB |
| Memory Slots | 2 |
| Storage | Dual M.2 2280 PCle4.0 X4 Max 8TB (4TB*2) |
| Storage Expansion | Dual M.2 2280 PCIe 4.0 x4 slots, max 8TB (4TB per slot) |
| Display Support | DP1.4(4K 144Hz)*1+HDMI 2.1(4K 120Hz)*1+USB4(40Gbps/TBT3/PD/DP1.4)*1 Support 4K Output |
| Network | 2.5Gbps Ethernet, WiFi 6, Bluetooth 5.2 |
| Wireless | WiFi 6 (Intel AX200) Bluetooth 5.2 |
| Bluetooth | Bluetooth 5.2 |
| Ethernet | 2.5Gbps, 1 port, Intel RTL8125B |
| I/O Ports | 1x HDMI 2.1, 1x DP1.4, 1x USB4 (Type-C), 2x USB3.2, 2x USB2.0, 1x RJ45 2.5G, 2x 3.5mm audio jacks |
| Front I/O | 2x USB3.2, 1x 3.5mm audio jack |
| Rear I/O | 1x HDMI 2.1, 1x DP1.4, 1x USB4 (Type-C), 2x USB2.0, 1x RJ45 2.5G, 1x 3.5mm audio jack |
| Dimensions | 0.814L 0.75Kg |
| Weight | 0.75 kg |
| Color / Finish | Frost Silver / Space Gray |
| Form Factor | Mini PC |
| Power | Input: 100-240V AC, 50/60Hz Output: 19V 5.26A |
| Power Options | US, EU, UK, AU, JP |
| Cooling | MSC 2.0 – Cooling System Vapor Chamber+Silent Fan+SSD Heatsink |
| Operating System | Windows 11 Pro |
| Operating System Options | Frost Silver, Space Gray |
| Audio | 2x 3.5mm audio jacks (headphone/mic) |
| Expansion Slots | 2x M.2 2280 PCIe 4.0 x4 (for SSD) |
| Support Included | Three-year warranty |
| Certifications | Energy Star |
| Package Contents | 1x SER8 8745HS, 1x User's Manual, 1x HDMI Cable, 1x Power Adapter (optional region) |
| Features | AUTO POWER ON WOL | About this item | - | Better Value, Unbeatable Performance --- Beelink SER8 mini PC is powered by an AMD Ryzen TM 7 8745HS processor with Max Turbo Frequency of 4.9GHz and AMD Radeon 780M iGPU. Equivalent to an 8845HS without the Ryzen AI Engine NPU, the 8745HS offers better value and equally unbeatable performance. | - Easy Expansion and New RAM Configuration--- SER8 8745HS supports dual-channel DDR5 5600MHz RAM of up to 256GB, allowing you to finish tasks in just a blink of an eye. Besides the existing 32GB(16GB*2) RAM option, now you can also choose a unit with 24GB(12GB*2) RAM. There are dual M.2 PCIe 4.0 SSD slots under the hood of the SER8, supporting up to 8TB of fast internal storage. | - 32dB Near-Silent Operation --- Air intake from the bottom is so efficient at dissipating the heat that SER8 needs very low fans peed to stay cool and stable at 65W TDP, ensuring near-silent operation. Since there are no vents on the top and side panels, SER8 can now have a more refreshing design. Integrated metal case not only offers excellent structural integrity but also acts as a noise dampener, providing a quiet computing experience. | - Ultra-Practical Dustproof Design --- The new h igh-density Metal filter at the bottom ensures optimal airflow, keeping dust out of the SER8. avoiding dust accumulation and dust-related issues. | - | Triple-display Output---With HDMI 2.1 & DisplayPort 1.4 & Full Featured USB4, SER8 support triple-display and 4K output. | - | Pre-Sale---Shipping within 35 days. | Our all power supply has a wide input voltage range from 100V to 240V. Although the US&JP power supply labels 100V-120V, it is safe to work with power source voltages anywhere between 100V to 240V. |
| Overview | Beelink SER8 mini PC powered by AMD Ryzen 7 8745HS with Radeon 780M, supports up to 256GB RAM and 8TB storage, triple display, WiFi 6, 2.5G LAN, Windows 11 Pro. |
| Warranty | Three-year Warranty |
| Configurations | 16G (8G*2) DDR5 5600MHz + 512GB SSD(Pre order) | 32G (16G*2) DDR5 5600MHz + 1TB SSD(Pre order) |
