AtomMan G1 PRO
AtomMan G1 PRO is a 3.8L mini PC with AMD Ryzen 9 8945HX (16 cores, up to 5.4GHz) and desktop-grade NVIDIA RTX 5060 8GB GDDR7. It features 32GB DDR5-5600 RAM, 1TB Gen4 SSD, dual M.2 slots, 2.5Gb Ethernet, WiFi 6E, Bluetooth 5.3, and up to 4 displays via HDMI 2.1, DP 1.4a, USB-C. Includes Windows 11 Pro and 350W PSU.
Pros
- +Powerful Ryzen 9 8945HX CPU
- +Desktop-grade RTX 5060 GPU
- +Up to 96GB RAM capacity
- +1TB SSD plus 2x M.2 slots
- +Wi-Fi 7 and Bluetooth 5.4
- +5GbE LAN port
Cons
- −Heavy at 8.4 lbs
- −No SD card slot
- −No USB4 or Thunderbolt port
- −Single audio jack
| Model | G1 PRO |
| Processor | AMD Ryzen™ 9 8945HX |
| Processor Model | Ryzen 9 8945HX |
| Processor Package | FL1 |
| Graphics | NVIDIA GeForce RTX 5060 (Desktop-Grade) |
| Memory | 32GB | 32GB RAM |
| Memory Slots | 2 (max 96 GB) |
| Storage | 1TB SSD |
| Storage Expansion | 2x M.2 2230/2280 NVMe slots (PCIe 4.0 x4, each up to 4 TB) |
| Display Support | Up to 5 displays: 2x HDMI 2.1 (8K@60Hz), 2x DP 2.1 (8K@120Hz), 1x DP 1.4a (8K@60Hz) |
| Wireless | Wi-Fi 7 |
| Bluetooth | 5.4 |
| Ethernet | 5 Gigabit LAN (RJ45, RTL8126) |
| I/O Ports | Front: 1x USB 3.2 Gen2 Type-A, 1x USB 3.2 Gen2 Type-C (data only), 1x 3.5mm combo audio jack, power button. Rear: 2x USB 3.2 Gen2 Type-A, 1x USB Type-C (data only), 2x HDMI 2.1, 2x DP 2.1, 1x DP 1.4a, 1x RJ45 5G LAN, AC input, power switch |
| Front I/O | 1x USB 3.2 Gen2 Type-A, 1x USB 3.2 Gen2 Type-C (data only), 1x 3.5mm combo audio jack, power button |
| Rear I/O | 2x USB 3.2 Gen2 Type-A, 1x USB Type-C (data only), 2x HDMI 2.1, 2x DP 2.1, 1x DP 1.4a, 1x RJ45 5G LAN, AC input, power switch |
| Dimensions | 215 x 57 x 315 mm (8.46 x 2.24 x 12.40 in) |
| Weight | 3.81 kg (8.4 lbs) |
| Color / Finish | White |
| Form Factor | Mini PC (vertical orientation) |
| Power | 350 W AC power supply |
| Cooling | Active cooling with 3 fans (CPU, system, SSD), 245 W total cooling capacity |
| Operating System | Windows 11 Pro |
| Operating System Options | Windows 11 / Linux |
| Audio | 3.5mm combo audio jack (4-in-1), HDMI/DP audio output |
| Expansion Slots | 2x M.2 2230/2280 NVMe (PCIe 4.0 x4), 1x PCIe 4.0 x16 (occupied by GPU) |
| Package Contents | AtomMan G1 Pro, user manual, HDMI cable, IEC C13/C14 AC cable, NVMe SSD heatsink, stand, necessary screws |
| Features | 3.8L compact volume, desktop-grade RTX 5060 GPU, 245W cooling, Ryzen 9 8945HX CPU, Wi-Fi 7, 5GbE LAN, RGB lighting, dedicated control center |
| Overview | Dominate e-sports and creation with the 3.8L MINISFORUM Mini PC G1 Pro. Packs a Ryzen 9 8945HX, a 145W desktop-grade RTX 5060, and 245W cooling for max FPS. |
| Warranty | 2 years limited (parts and labor) |
| Configurations | 32GB RAM+1TB SSD |
Specs on this page may not be 100% accurate — please verify with the manufacturer.
