GMKtec G5S Mini PC Intel Celeron N5095
The GMKtec G5S Mini PC features an Intel Celeron N5095 processor, 8GB non-upgradable LPDDR4 RAM, and a 128GB M.2 SATA SSD (expandable to 8TB). It supports dual 4K@60Hz via HDMI 2.0, Wi-Fi 6, Bluetooth 5.2, and Gigabit Ethernet. Ultra-compact at 72x72x44.5mm, it runs Windows 11 Pro and is suitable for office, home, and digital signage.
| Model | G5S |
| Processor | Intel Celeron Processor N5095 | 4 Cores / 4 Threads | Base Frequency: 2.0 GHz | Burst Frequency: Up to 2.9 GHz | 4MB Intel Smart Cache | 10nm Process Technology | TDP: 10W |
| Processor Model | Intel Celeron N5095 |
| Processor Technology | 10nm |
| Processor Package | BGA |
| Chipset | Intel SoC (integrated) |
| Graphics | Intel UHD Graphics | Base Frequency: 450 MHz | Burst Frequency: Up to 750 MHz | Supports 4K Video Output |
| Memory | LPDDR4 2400MT/s RAM | 8GB Onboard Memory | Non-upgradable |
| Memory Slots | 0 (onboard, non-upgradable), max 8GB |
| Storage | M.2 2242 SATA 3.0 SSD | 128GB Pre-installed SSD | Supports PCIe Gen3 x2 NVMe & SATA SSD | Expandable up to 8TB |
| Storage Expansion | 1x M.2 2242 slot (supports SATA and PCIe Gen3 x2 NVMe), expandable up to 8TB |
| Display Support | Dual HDMI 2.0 Output | Supports Dual 4K @ 60Hz Displays |
| Network | WiFi 6 (802.11ax), Bluetooth 5.2, Gigabit Ethernet (RTL8111H) |
| Wireless | WiFi 6 (802.11ax/ac/a/b/g/n) |
| Bluetooth | Bluetooth 5.2 |
| Ethernet | Gigabit Ethernet (RTL8111H), 1 port |
| I/O Ports | Front: 2x USB-A 3.2 Gen1, Power button; Rear: 2x HDMI 2.0, 1x USB-A 3.2 Gen1, 1x USB-C (power input), 1x 3.5mm audio combo jack, 1x Gigabit RJ45 LAN |
| Front I/O | 1 x Power Button with Blue LED Indicator | 2 x USB-A 3.2 Gen1 (5Gbps) |
| Rear I/O | 2 x HDMI 2.0 (4K@60Hz) | 1 x USB-A 3.2 Gen1 (5Gbps) | 1 x USB-C Power Input | 1 x 3.5mm Audio Combo Jack | 1 x Gigabit RJ45 LAN (RTL8111H) |
| SD Card | Micro SD Card Slot, supports up to 128GB |
| Dimensions | 72 x 72 x 44.5 mm |
| Weight | Approx. 206g |
| Form Factor | Mini PC, ultra-compact |
| Power | USB Type-C Power Input, 12V / 3A Adapter, built-in CMOS battery |
| Cooling | Copper Heat Pipe Cooling | Single Cooling Fan | Efficient 10W Low-Power Thermal Design |
| Operating System | Windows 11 Pro |
| Operating System Options | Windows 11 Pro (regional variants: US, EU, UK, AU) |
| Audio | 3.5mm audio combo jack |
| Expansion Slots | 1x M.2 2242 (storage), 1x Micro SD card slot |
| Security | Security Lock Slot (Kensington lock) |
| Kensington Lock | Yes |
| Features | Auto Power On Supported, BIOS Setting Available, Dual 4K@60Hz, Wi-Fi 6, Bluetooth 5.2, Gigabit Ethernet, Ultra-Compact Design |
| Overview | GMKtec Nucbox G5S Mini PC, powered by the Intel Celeron N5095 processor delivers reliable performance for everyday computing, office work, home entertainment, digital signage, and light business applications. Featuring a quad-core processor with speeds up to 2.9GHz, 8GB LPDDR4 onboard memory, and a 128GB M.2 2242 SATA SSD, it also supports PCIe Gen3x2 NVMe and SATA SSD expansion up to 8TB for flexible storage upgrades. Dual HDMI 2.0 ports enable dual 4K@60Hz display output, making multitasking more efficient. Equipped with Wi-Fi 6, Bluetooth 5.2, and Gigabit Ethernet, it provides fast and stable connectivity for work and streaming. Its ultra-compact 72 x 72 x 44.5 mm design saves valuable desk space while offering powerful functionality, making it an ideal Mini PC for home offices, education, retail, kiosks, and business environments. |
| Configurations | 8GB+128GB |
Specs on this page may not be 100% accurate — please verify with the manufacturer.
