GMKtec EVO-X1 Pro AI Mini PC AMD Ryzen™ AI 9 HX 470
Pros
- +High-performance 12-core/24-thread AMD Ryzen AI processor
- +Powerful Radeon 890M integrated graphics
- +Large 64GB onboard LPDDR5 memory
- +Wi-Fi 7 and Bluetooth 5.4
- +Dual 2.5G Ethernet ports
- +Triple display output up to 8K
Cons
- −Memory is onboard and non-upgradeable
- −SATA SSDs not supported
- −OCuLink lacks hot-plug support
| Model | EVO-X1 Pro |
| Processor | AMD Ryzen™ AI 400 Series Processor 12 Cores / 24 Threads (4 × Zen 5 + 8 × Zen 5c) TSMC 4nm FinFET Process Base Clock: 2.0GHz Max Boost Clock: Up to 5.2GHz 12MB L2 Cache / 24MB L3 Cache |
| Processor Model | AMD Ryzen™ AI 9 HX 470 |
| Processor Technology | TSMC 4nm FinFET Process |
| Graphics | AMD Radeon™ 890M Graphics 16 Compute Units Graphics Frequency: Up to 3.1GHz |
| NPU / AI Accelerator | AMD Ryzen™ AI Dedicated NPU Performance: Up to 55 TOPS Total AI Performance: Up to 86 TOPS GMKtec Claw Pre-installed for Ready-to-use Local AI |
| Memory | 64GB Onboard LPDDR5 6400MT/s Memory Onboard, Non-upgradeable |
| Memory Slots | 0 (onboard, non-upgradeable) |
| Storage | Dual M.2 2280 PCIe 4.0 ×4 SSD Slots Standard Configurations: 1TB / 2TB Supports PCIe 3.0 & PCIe 4.0 NVMe SSD Maximum Capacity: Up to 16TB (8TB per slot) SATA SSD Not Supported |
| Storage Expansion | Dual M.2 2280 PCIe 4.0 ×4 slots, supports up to 16TB total |
| Display Support | Triple Display Output 1 × HDMI 2.1 (Up to 8K@60Hz) 1 × DisplayPort 2.1 (Up to 8K@60Hz) 1 × USB4 Display Output (Up to 4K@60Hz) |
| Network | Dual 2.5G Ethernet (Intel I226-V ×2) |
| Wireless | Wi-Fi 7 (AMD RZ717 / MediaTek MT7925) Maximum Wireless Speed: Up to 2.9Gbps Bluetooth 5.4 Dual 2.5G Ethernet (Intel I226-V ×2) |
| Bluetooth | Bluetooth 5.4 |
| Ethernet | Dual 2.5G Ethernet (Intel I226-V ×2) |
| I/O Ports | 4× USB 3.2 Gen2 Type-A (10Gbps), 1× USB4 (40Gbps, PD 3.0, Display Output), 1× OCuLink (PCIe 4.0 ×4), 1× HDMI 2.1, 1× DisplayPort 2.1, 2× RJ45 2.5G Ethernet, 1× 3.5mm Audio Jack, 1× DC IN, 1× Kensington Lock |
| Front I/O | 2 × USB 3.2 Gen2 Type-A (10Gbps) 1 × Full-featured USB4 (40Gbps, PD 3.0, Display Output) 1 × OCuLink (PCIe 4.0 ×4) 1 × 3.5mm CTIA Audio Jack 1 × Power Button (White LED) 1 × Reset Button |
| Rear I/O | 2 × USB 3.2 Gen2 Type-A (10Gbps) 1 × HDMI 2.1 (Up to 8K@60Hz) 1 × DisplayPort 2.1 (Up to 8K@60Hz) 2 × RJ45 2.5G Ethernet 1 × DC IN (5.5 × 2.5mm) 1 × Kensington Security Lock |
| Dimensions | 107 × 111 × 63mm |
| Weight | Approx. 590g |
| Color / Finish | Metal Grey |
| Form Factor | Mini PC |
| Power | DC Input: 19V / 6.32A 120W Power Adapter Included USB4 Supports PD 3.0 Power Input (Up to 100W) Built-in CMOS Battery |
| Cooling | Vapour Chamber Dual-fan Cooling System Dedicated System Fan with Integrated Lighting Silent Mode: 35W Balanced Mode: 54W Performance Mode: Up to 65W Peak |
| Operating System | Windows 11 Pro |
| Software Included | GMKtec Claw |
| Audio | 1 × 3.5mm CTIA Audio Jack |
| Expansion Slots | Dual M.2 2280 PCIe 4.0 ×4 slots (for SSD), 1× OCuLink PCIe 4.0 ×4 (for external GPU) |
| Security | Kensington Security Lock |
| Package Contents | 120W Power Adapter, HDMI Cable, Stand, User Manual, Warranty Card |
| Kensington Lock | Yes, rear panel |
| Features | OCuLink does not support hot-plugging. Please connect or disconnect OCuLink devices only when the Mini PC is fully powered off. |
| Overview | GMKtec EVO-X1 Pro is a compact AI mini PC powered by AMD Ryzen AI 9 HX 470 processor with Radeon 890M graphics, 64GB LPDDR5 memory, dual M.2 SSD slots, and OCuLink for external GPU. It features Wi-Fi 7, Bluetooth 5.4, dual 2.5G Ethernet, and triple display output up to 8K. Pre-installed with Windows 11 Pro and GMKtec Claw AI software. |
| Warranty | 1-Year Warranty |
| Configurations | Standard configurations: 1TB or 2TB SSD |
Specs on this page may not be 100% accurate — please verify with the manufacturer.
