MINISFORUM BD795M
Pros
- +Powerful 16-core Ryzen 9 7945HX
- +Supports DDR5 up to 96GB
- +Dual M.2 slots with PCIe 5.0
- +PCIe 5.0 x16 expansion slot
- +HDMI 2.1 output
- +Compatible with LGA 1700 coolers
Cons
- −No RAM included
- −No storage included
- −No cooler included
- −No power supply included
- −No built-in Ethernet
- −No wireless connectivity built in
| Model | BD795M |
| Processor | AMD Ryzen™ 9 7945HX |
| Processor Model | Ryzen 9 7945HX |
| Graphics | AMD Radeon 610M |
| Memory | DDR5 SO-DIMM, up to 96GB, 5200 MT/s |
| Memory Slots | 2 x SO-DIMM, max 96GB |
| Storage | Up to 4TB NVMe SSD |
| Storage Expansion | 2x SATA III ports |
| Display Support | 1x HDMI 2.1 |
| I/O Ports | 2x USB 3.2 Gen1, 2x USB 2.0, 1x HDMI 2.1, 1x PCIe 5.0 x16, audio jacks |
| Dimensions | 240mm x 220mm x 1.6mm (PCB thickness) |
| Form Factor | M-ATX |
| Power | No included power supply; supports standard ATX PSU |
| Cooling | No included cooler; supports standard LGA 1700 air/liquid cooling |
| Operating System | No OS |
| Expansion Slots | 1x PCIe 5.0 x16, 2x M.2 2280 (1x PCIe 5.0, 1x PCIe 4.0), 2x SATA III |
| Package Contents | BD795M motherboard, AMD Ryzen 9 7945HX processor (soldered), AMD Radeon 610M graphics; no RAM, no storage, no cooler, no power supply |
| Features | Supports standard LGA 1700 coolers, AIO pump connector, TDP 100W (configurable to 120W), no SSD heatsink |
| Overview | Minisforum BD795M is a M-ATX motherboard with integrated AMD Ryzen 9 7945HX processor, offering 16 cores/32 threads, up to 5.4GHz. It features DDR5 SO-DIMM memory support up to 96GB, two M.2 NVMe slots (one PCIe 5.0), two SATA ports, a PCIe 5.0 x16 slot, and HDMI 2.1 output. No CPU cooler, RAM, storage, or power supply included. |
| Warranty | 1 Year Limited (Parts and Labor) |
Specs on this page may not be 100% accurate — please verify with the manufacturer.
