GMKtec NucBox M2 Pro S Mini PC Intel Core™ i7-1185G7
The GMKtec NucBox M2 Pro S is a compact mini PC powered by an Intel Core i7-1185G7 processor with Iris Xe graphics. It supports up to 64GB DDR4 RAM and dual M.2 SSDs (PCIe 4.0 and SATA). Features include WiFi 6, Bluetooth 5.2, 2.5GbE LAN, triple 4K display output, and Windows 11 Pro.
Pros
- +Fast Intel Core i7-1185G7
- +Iris Xe graphics with 96 execution units
- +Supports up to 64GB RAM
- +Dual M.2 SSD slots up to 10TB
- +Wi-Fi 6 and Bluetooth 5.2
- +2.5GbE Ethernet
Cons
- −No SD card slot
- −No Thunderbolt or USB4
- −M.2 2242 slot SATA only
- −DDR4 memory only
| Model | GMKtec NucBox M2 Pro S |
| Processor | 11th Gen Intel® Core™ i7 Processor, 4 Cores, 8 Threads, 10nm process, Max Turbo Frequency up to 4.8GHz, 12MB L3 Cache |
| Processor Model | Intel® Core™ i7-1185G7 Processor |
| Processor Technology | 10nm |
| Processor Package | FCBGA1449 Package, 45.5 × 25 mm |
| Graphics | Intel® Iris® Xe Graphics, 96 Execution Units, Max Dynamic Frequency up to 1.35GHz |
| Memory | 2 × SO-DIMM Slots, 16GB / 32GB configurations, Supports up to 64GB |
| Memory Slots | 2 x SO-DIMM, max 64GB |
| Storage | 2 × M.2 SSD Slots, 512GB NVMe SSD pre-installed |
| Storage Expansion | 1 × M.2 2280 SSD slot, supports up to 8TB 1 × M.2 2242 SSD slot, supports up to 2TB Maximum total storage capacity: up to 10TB |
| Display Support | Triple display output via 2 × HDMI + 1 × USB-C, supports up to 4K resolution |
| Wireless | Wi-Fi 6 (Realtek 8852BE, up to 1201 Mbps) Bluetooth 5.2 2.5G Ethernet LAN (Intel I226-V) |
| Bluetooth | Bluetooth 5.2 |
| Ethernet | 2.5G Ethernet LAN (Intel I226-V), 1 x RJ45 |
| I/O Ports | USB-A: 2 × USB 3.2 Gen2 (10Gbps) + 1 × USB 3.2 Gen1 (5Gbps) + 1 × USB 2.0 USB-C: 1 × Type-C (DisplayPort / Data, up to 4K@60Hz / 5Gbps) HDMI: 2 × HDMI 2.0 (up to 4K@60Hz) Audio: 1 × 3.5mm CTIA Audio Jack LAN: 1 × RJ45 2.5G Ethernet Power: 1 × DC IN (5.5/2.5mm) |
| Dimensions | 114 × 106 × 42.5 mm |
| Weight | 361 g |
| Color / Finish | Gray |
| Form Factor | Mini PC (NUC-like) |
| Power | Built-in coin cell battery DC Power Adapter 20V / 5A, 100W |
| Power Options | US, EU, UK, AU |
| Cooling | Cooling Fan |
| Operating System | Windows 11 Pro |
| Operating System Options | US, EU, UK, AU |
| Audio | 1 x 3.5mm CTIA Audio Jack |
| Expansion Slots | 2 x M.2 slots (1x 2280 PCIe 4.0, 1x 2242 SATA) |
| Environmental | 0°C to 40°C |
| Certifications | CCC, CE, FCC, RoHS, MIC, CEC, China Energy Label, UL Report |
| Package Contents | User Manual Warranty Card Power Adapter VESA Mount Bracket HDMI Cable |
| Features | 14 Languages Supported (Default English): Simplified Chinese, Traditional Chinese, French, Dutch, Italian, Spanish, Korean, Japanese, German, Hebrew, Russian, Portuguese, Arabic |
| Overview | GMKtec NucBox M2 Pro S Mini PC powered by Intel Core TM i7-1185G7 processor (4 cores / 8 threads, up to 4.8GHz) with Iris Xe graphics. Supports DDR4 memory up to 64GB and dual M.2 SSD expansion for flexible storage. Equipped with WiFi 6, 2.5GbE LAN, multiple USB ports, and triple-display output via dual HDMI and USB-C. Its compact design delivers strong performance for office productivity, multitasking, content creation, and everyday business computing. |
| Warranty | 1-Year Limited Warranty |
| Configurations | Barebone (No DDR & SSD & OS) | 16GB RAM+512GB SSD | 32GB RAM+1TB SSD |
Specs on this page may not be 100% accurate — please verify with the manufacturer.
