MINISFORUM AI X1
The MINISFORUM AI X1 is a compact mini PC (128x126x52mm, 0.6kg) offering AMD Ryzen 7 255/260 (Zen 4) or Ryzen AI 9 365 (Zen 5) processors, Radeon 780M/880M graphics, and up to 50 TOPS NPU on AI model. Supports up to 128GB DDR5, dual M.2 NVMe, quad displays via HDMI 2.1/DP 2.0/USB4, 2.5GbE LAN, Wi-Fi 7, Bluetooth 5.4, and OCuLink for eGPU.
Pros
- +8-core Zen 4 processor
- +Fast DDR5 memory up to 64GB
- +Dual NVMe SSD slots
- +8K display output support
- +Wi-Fi 7 and Bluetooth 5.4
- +2.5 Gigabit Ethernet
Cons
- −No dedicated GPU
- −No SD card slot
- −Single 2.5GbE port
| Model | AI X1 |
| Processor | AMD Ryzen™ 7 260 8 cores, 16 threads |
| Processor Model | Ryzen 7 260 |
| Processor Technology | Zen 4 |
| Graphics | AMD Radeon™ 780M |
| Memory | DDR5(SO-DIMMx2) 5600MT/s, max, 64GB |
| Memory Slots | 2 |
| Storage | 2× M.2 2280 NVME SSD Slot（up to 4TB） |
| Storage Expansion | 2x M.2 2280 NVMe, up to 4TB |
| Display Support | HDMI x 1 (Up to 8K@60Hz/4K@120Hz) DP x 1 (Up to 8K@60Hz/4K@120Hz) USB4 х 2 (Up to 8K@60Hz/4K@120Hz) |
| Network | Wi-Fi 7, Bluetooth 5.4, 2.5 Gigabit LAN |
| Wireless | Wi-Fi 7, Bluetooth® 5.4 |
| Bluetooth | 5.4 |
| Ethernet | 2.5 Gigabit LAN, 1 port |
| I/O Ports | 2.5Gigabit LAN(RJ45) х 1 USB Type A(USB3.2 Gen2) х 2 USB Type A(USB2.0) х 1 USB4 х 1(Alt PD in 100W & PD Out 15W, In Rear) USB4 х 1(Alt PD Out 15W, In Front) HDMI 2.1 х 1 DP2.0 x 1 3.5mm Audio Jack х 1 DMICx2 OCuLink х 1 (via M.2 to OCuLink adapter board) |
| Front I/O | 1x USB4 (Alt PD Out 15W), 1x 3.5mm Audio Jack, 2x DMIC |
| Rear I/O | 1x 2.5G LAN, 2x USB Type A (USB3.2 Gen2), 1x USB Type A (USB2.0), 1x USB4 (Alt PD in 100W & PD Out 15W), 1x HDMI 2.1, 1x DP2.0, 1x OCuLink |
| Dimensions | 128×126×52mm(LWH) |
| Weight | 0.6Kg |
| Form Factor | Mini PC |
| Power | DC-IN 19V/6.32A 120W |
| Operating System | Windows 11 |
| Audio | HDMIx1 3.5mm Combo Jack x 1 Speaker x2 | DMICx 2 3.5mm Combo Jackx1 |
| Expansion Slots | 2x M.2 2280 NVMe |
| Features | AI capabilities, OCuLink, USB4, Wi-Fi 7 |
| Overview | Experience next-level AI technology that supercharges multitasking, boosts productivity, enhances teamwork, and delivers efficiency like never before. |
| Configurations | Barebone(NO OS&RAM&SSD) | 32GB RAM+1TB SSD | 64GB RAM+1TB SSD |
Specs on this page may not be 100% accurate — please verify with the manufacturer.
